E-Z-GO TXT
The E-Z-GO® TXT® golf car combines proven reliability with the industry’s latest innovations to deliver a consistently smoother ride and greater energy efficiency. Featuring a 48-volt electric drivetrain and TruCourse™ Technology, it offers the perfect balance of performance and efficiency to your course.
- Electric Specs
- GAS SPECS
| BODY & CHASSIS | |
|---|---|
| Frame | Welded steel with powder coating |
| Front Body & Finish | Injection-molded TPO |
| Rear Body & Finish | Injection-molded TPO |
| Standard Color | Ivory or Forest Green |
| DIMENSIONS | |
|---|---|
| Overall Length | 93.0 in (236 cm) |
| Overall Width | 47.0 in (119 cm) |
| Overall Height (no canopy) | 46.5 in (118 cm) (top of steering wheel) |
| Overall Height (with canopy) | 67.5 in (171 cm) (top of sun canopy) |
| Wheel Base | 66.0 in (168 cm) |
| Front Wheel Track | 34.0 in (86 cm) |
| Rear Wheel Track | 38.5 in (97 cm) |
| Ground Clearance (at differential) | 4.5 in (11 cm) |
| POWER | |
|---|---|
| Power Source | 48-volt DC |
| Motor Type | Shunt Wound |
| Horsepower (kW) | 3.0 hp (2.2 kW) Continuous |
| Electric System | 48-volt |
| Batteries (qty/type) | Six, 8-volt deep cycle |
| Key or Pedal Start | Pedal |
| Battery Charger | 48 VDC PowerWise™ QE, 120 VAC, UL & CSA |
| Speed Controller | 250-amp solid-state controller |
| Drive Train | Motor shaft direct drive |
| Transaxle | Differential with helical gears |
| Gear Selection | Dash-mounted forward-neutral-reverse |
| Rear Axle Ratio | 12.44:1 |
| Warranty | Standard: 20,000 amp/hr Platinum: 21,500 amp/hr - optional Diamond: 25,000 amp/hr - optional |
| TruCourse Programmable Modes | Coastal, Mild hill, Steep hill |
| PERFORMANCE | |
|---|---|
| Seating Capacity | 2-person |
| Dry Weight (without batteries) | 557 lb (253 kg) |
| Curb Weight | 935 lb (424 kg) |
| Vehicle Load Capacity | 800 lb (363 kg) |
| Outside Clearance Circle | 19.0 ft (5.8 m) |
| Speed (level ground) | 10.2-14.8 mph (16.4-23.8 kph) |
| Towing Capacity | 3 E-Z-GO golf cars with approved permanent tow bar |
| STEERING & SUSPENSION | |
|---|---|
| Steering | Self-compensating rack and pinion |
| Front Suspension | Leaf springs with hydraulic shock absorbers |
| Rear Suspension | Leaf springs |
| Service Brake | Rear wheel mechanical self-adjusting drum |
| Parking Brake | Self-compensating single-point engagement |
| Front Tires | 18 x 8.50-8 (4-ply rated) |
| Rear Tires | 18 x 8.50-8 (4-ply rated) |
| BODY & CHASSIS | |
|---|---|
| Frame | Welded steel with powder coating |
| Front Body & Finish | Injection-molded TPO |
| Rear Body & Finish | Injection-molded TPO |
| Standard Color | Ivory or Forest Green |
| DIMENSIONS | |
|---|---|
| Overall Length | 93.0 in (236 cm) |
| Overall Width | 47.0 in (119 cm) |
| Overall Height (no canopy) | 46.5 in (118 cm) (top of steering wheel) |
| Overall Height (with canopy) | 67.5 in (171 cm) (top of sun canopy) |
| Wheel Base | 66.0 in (168 cm) |
| Front Wheel Track | 34.0 in (86 cm) |
| Rear Wheel Track | 38.5 in (97 cm) |
| Ground Clearance (at differential) | 4.25 in (10.8 cm) |
| POWER | |
|---|---|
| Power Source | 4-Cycle 24.5 cu in (401 cc) low-emissions |
| Valve Train | Single-cylinder OHV with hemispheric combustion chamber |
| Horsepower (kW) | 13.5 hp (10.1 kW) exceeds SAE J1940 Std. |
| Electric System | Starter/Generator, Solid-State Regulator |
| Batteries (qty/type) | One, 12-volt maintenance-free |
| Key or Pedal Start | Pedal |
| Air Cleaner | Industrial-rated dry filter |
| Lubrication | Pressurized oil system |
| Fuel Capacity | 5.3 gallon (20.0 L) tank |
| Drive Train | Continuously variable transmission (CVT) |
| Transaxle | Differential with helical gears |
| Gear Selection | Forward-Reverse |
| Rear Axle Ratio | 11.42:1 (forward), 15.78:1 (reverse) |
| Oil Filter | Spin On |
| Cooling System | Air Cooled |
| PERFORMANCE | |
|---|---|
| Seating Capacity | 2-person |
| Dry Weight | 760 lb (344 kg) |
| Curb Weight | 780 lb (354 kg) |
| Vehicle Load Capacity | 800 lb (363 kg) |
| Outside Clearance Circle | 19.0 ft (5.8 m) |
| Speed (level ground) | 13 mph +/- 0.5 mph (21 kph +/- 0.8 kph) |
| Towing Capacity | 3 E-Z-GO golf cars with approved permanent tow bar |
| STEERING & SUSPENSION | |
|---|---|
| Steering | Self-compensating rack and pinion |
| Front Suspension | Leaf springs with hydraulic shock absorbers |
| Rear Suspension | Leaf springs with hydraulic shock absorbers |
| Service Brake | Rear wheel mechanical self-adjusting drum |
| Parking Brake | Self-compensating single-point engagement |
| Front Tires | 18 x 8.50-8 (4-ply rated) |
| Rear Tires | 18 x 8.50-8 (4-ply rated) |
