North Shore Golf Car offers premium golf cars, utility vehicles, rentals, service, parts, and customization since 1980

Cushman - HAULER PRO-X

Push the limits of the day with the lifted suspension of the Hauler PRO-X, exclusively offered in ELiTE lithium battery technology. Built for facilities and properties that need added capability on rougher terrain, the PRO-X adds more ground clearance and a more confident stance while keeping the same zero-maintenance electric utility advantages as the Hauler PRO platform.

The Hauler PRO-X is designed for operators who regularly deal with uneven surfaces, longer work routes, and real hauling demands. Cushman pairs its ELiTE lithium drivetrain with rugged tires, automatic parking brake, and limited-slip differential to create a utility vehicle that works hard without feeling stripped down or basic.

Beyond the lifted suspension, the PRO-X keeps the practical details that matter during the workday, including a highly functional dash, optional IntelliGauge controls, accessory flexibility, and the ability to configure the vehicle for specialized jobs. It is a strong fit for grounds crews, golf operations, resorts, campuses, and commercial properties.

Click main image to enlarge and browse the gallery.

Cushman positions the Hauler PRO-X as the lifted version of the Hauler PRO, created for operators who need to confidently venture through rough terrain with rugged tires, higher ground clearance, and an unrelenting ELiTE lithium powertrain.

The ELiTE lithium battery powered by Samsung SDI technology is designed to deliver remarkable range, zero maintenance, and opportunity charging, helping crews stay productive longer without battery watering, equalizing, or the downtime associated with older battery systems.

Standard lifted suspension, automatic parking brake, and a purpose-built utility layout make the PRO-X a practical work vehicle for demanding sites where a standard low-clearance utility platform may not be enough.

  • ELiTE lithium electric drivetrain
  • Lifted suspension for higher ground clearance
  • Rugged tires for rougher terrain
  • Zero-maintenance battery system
  • 5-year battery warranty
  • Automatic parking brake
  • Highly functional dash with ample storage
  • Optional IntelliGauge for greater vehicle control and security
  • Optional long-handled tool rack
  • Custom Solutions accessory support for job-specific builds
Cushman Hauler PRO-X ELiTE
Frame
Welded Steel with E-Coat DuraShield powder coat
Body & Finish
Injection Molded TPO
Vehicle Colors
Forest Green, Patriot Blue, Bright White, Flame Red, Black
Powertrain
ELiTE Lithium Electric only
Power Source
56.7V Li-Ion battery
Motor Type
AC induction
Horsepower
14.9 hp (11.1 kW)
Electrical System
48V primary, 12V auxiliary
Battery Type
4.2 ELiTE twin pack
Battery Charger
811 watt world charger
Key or Pedal Start
Pedal
Speed Controller
350 amp AC controller
Drive Train
Motor shaft direct drive
Transaxle
Limited-slip differential with helical gears
Gear Selection
Dash mounted forward-neutral-reverse / key switch
Rear Axle Ratio
16.99:1
Overall Length
119 in (302 cm)
Overall Width
49 in (125 cm)
Overall Height
74.5 in (189.2 cm)
Wheel Base
76.8 in (195 cm)
Wheel Track
Front: 35 in (88.9 cm), Rear: 38.5 in (97.8 cm)
Ground Clearance
6.3 in (16 cm)
Cargo Deck Capacity
12 cu ft (0.34 cu m)
Cargo Deck Material
Roto-Molded Polyethylene
Seating Capacity
2 person
Curb Weight
954 lb (433 kg)
Vehicle Load Capacity
1200 lb (544 kg)
Bed Load Capacity
500 lb (227 kg)
Outside Clearance Circle
21.5 ft (6.6 m)
Speed
16.5 mph +/- 0.5 mph (26.5 kph +/- 0.8 kph)
Steering
Self-compensating rack and pinion
Suspension
Leaf springs with hydraulic shock absorbers
Service Brake
Dual rear wheel mechanical, self-adjusting drum
Parking Brake
Automatic electro-magnetic
Tire Pressure Range
18 - 22 psi (124 - 152 kPa)

Need Pricing or Availability?

Contact North Shore Golf Car for current inventory, powertrain options, and availability on the Cushman Shuttle 6.
