EXPRESS S4

The E-Z-GO Express S4 is built for riders who want the versatility of a four-passenger vehicle with the flexibility of a rear seat that converts into a cargo deck. It is a practical choice for neighborhoods, larger properties, resorts, campgrounds, and everyday recreational use.

Available in both gas and ELiTE lithium power, the Express S4 gives buyers the option to choose traditional fuel convenience or quiet electric performance. Its lifted stance, roomy seating, and utility-minded layout make it one of the most flexible vehicles in the Express family.

Click main image to enlarge and browse the gallery.

Express S4 ELiTE Lithium

Overall Length

114.6 in (291 cm)

Overall Width

49.6 in (126 cm)

Overall Height (No Canopy)

52.0 in (132 cm)

Overall Height (With Canopy)

81.9 in (208 cm)

Wheel Base

67.4 in (171 cm)

Ground Clearance

7.3 in (18.5 cm) at differential

Power Source

39.2-56.7V Li-Ion battery

Motor Type

AC induction

Horsepower

11.7 hp (8.7 kW)

Electrical System

48V primary, 12V auxiliary

Battery Type

Single 56.7V Li-Ion composite module

Battery Charger

56.7V 350W domestic charger, 3m charging cord

Speed Controller

235-amp AC controller

Drivetrain

Motor shaft direct drive

Transaxle

Clutch type limited-slip differential with helical gears

Gear Selection

Dash mounted FNR/key switch

Rear Axle Ratio

16.99:1 (forward)

Top Speed

19.5 mph (31.4 kph) max

Seating Capacity

4-person

Dry Weight

918 lb (416 kg) without batteries

Curb Weight

965 lb (437 kg)

Vehicle Load Capacity

800 lb (363 kg)

Outside Clearance Circle

22.8 ft (7.0 m)

Steering

Self-compensating reduction rack and pinion

Front Suspension

Leaf springs with hydraulic shock absorbers

Rear Suspension

Leaf springs with hydraulic shock absorbers

Brakes

Dual rear wheel mechanical self-adjusting drum

Parking Brake

Automatic electromagnetic

Tires

Loadstar Daytona 205/65/10 or Paramount M/T 23x10-14

Frame

Welded steel with DuraShield powder coat and e-coat

Body and Finish

Injection molded TPO

Express S4 Gas

Overall Length

115.6 in (293 cm)

Overall Width

48.5 in (123 cm)

Overall Height (No Canopy)

52.5 in (133 cm)

Overall Height (With Canopy)

83.0 in (210 cm)

Load Deck Width

39.5 in (100 cm)

Load Deck Length

33.75 in

Wheel Base

65.5 in (166 cm)

Front Wheel Track

38.5 in (98 cm)

Rear Wheel Track

38.5 in (98 cm)

Ground Clearance

6.0 in (15 cm) at differential

Engine

Walbro 4-cycle 24.5 in³ (401 cc)

Valvetrain

Single cylinder OHV

Horsepower

13.5 hp (10.1 kW)

Cooling System

Air cooled

Electrical System

Starter / generator, solid state regulator

Battery

12-volt maintenance-free

Fuel System

Closed-loop electronic fuel injection

Fuel Capacity

5.96 gallon (22.6 L)

Drivetrain

Automatic, continuously variable transmission (CVT)

Transaxle

Differential with helical gears

Gear Selection

Forward - Reverse

Rear Axle Ratio

11.47:1 forward, 14.35:1 reverse

Seating Capacity

4-person

Dry Weight

1061 lb (481 kg)

Curb Weight

1101 lb (499 kg)

Load Deck Capacity

300 lb (136 kg)

Vehicle Load Capacity

800 lb (363 kg)

Outside Clearance Circle

22 ft (6.7 m)

Top Speed

19 mph (31 kph) max

Steering

Self-compensating reduction rack and pinion

Front Suspension

Leaf springs with hydraulic shock absorbers

Rear Suspension

Leaf springs with hydraulic shock absorbers

Brakes

Dual rear wheel mechanical self-adjusting drum

Parking Brake

Self-compensating, single point engagement

Tires

Paramount M/T 23x10-14, Kenda K500 20x8.5-10, Kenda K399 205/65-10, or Loadstar Daytona 205/65-10

Frame

Welded steel with DuraShield powder coat

Front Body and Finish

Injection molded TPO

Rear Body and Finish

Injection molded TPO

Standard Color

Black

Express S4 Highlights

Passenger Capacity

Comfortable seating for four

Rear Seat Function

Rear-facing seat converts into a practical cargo deck

Power Choices

Available in gas and ELiTE lithium electric configurations

Common Uses

Neighborhood cruising, large properties, resorts, events, recreational driving

Ride Character

Lifted style with passenger comfort and everyday versatility

Why Buyers Like It

Balances passenger seating, utility, and flexible power options in one model
